Included:

• Tub Drain Rough
• Installation accessories
• Qty: 1

Documents:

• Spec Sheet (.PDF)
• Installation Instruction (.PDF)

[/additional]

Install a Freestanding bath tub in minutes with the Island Tub Drain®. No muss, no fuss, no kidding.- Newly redesigned Asymmetrical Deck Flange makes installation in tight spaces easier- Allows for freestanding Tub location to be defined at rough-in- Designed to be installed in a 8" (1-1/2" outlet) or 10" (2" outlet recommended) joist space- Allows for freestanding Tub to be installed over finished floor- Built-in Snap-off Test Cap allows for water/air/smoke testing- NOTE: Island Tub Drain® IS NOT FOR USE with liquid applied or sheet membranes- NOTE: Island Tub Drain® MUST BE INSTALLED in a dry area with no potential of water contact

Features:

• Snap-off Test Cap allows for water/air/smoke testing (Rated to 30psi)
• 18 Gauge Epoxy coated Asymmetrical Metal Deck Plate with holes to lock in Thinset
• ITD35™ is a Freestanding Tub Rough-in (install before tile installation)
• Designed to be installed in a 8" / 10" joist space with 1-1/2" / 2" P-Trap
• Flanged Brass Tailpiece
• ABS Adapter Kit (attaches ITD35™ to ABS Bath Waste)
• Island Drain assembly
• Mortar/Tile guard
• Cutting Template
• Material: ABS
• Finish/Color: Black
• Dimensions: W: 7" * H: 3,75" * D: 6,25"
• Weight: 00 lb.
• Rustproof: Yes
• Warranty (Years): 1
• Material Warranty: Yes
• Finish Warranty: Yes
• UPC Certified: Yes
